Introduction

SAP Asset Performance Management (APM) automatically comes with Embedded IoT capabilities powered by Cumulocity. In our first post, we (the topic experts from Cumulocity) showed you how to get started by simply connecting your smartphone sensors. Then we proceeded to show how to connect an OPC-UA server. Today, we want to go the next step and present an integration to AVEVA PI Server, one of the most popular industrial data historians.

AVEVA PI Connector for Cumulocity

Industrial historians like AVEVA PI System are the backbone of operational data in many manufacturing and energy environments, storing decades of high-frequency time-series data from sensors, PLCs, and SCADA systems. However, that data often remains siloed — inaccessible to modern IoT platforms, cloud analytics, and digital twin solutions.

Unlocking this data opens the door to an entirely new class of use cases. Until now, many teams have been unable to act on the full potential of their Historian data simply because it never left the plant floor. Bringing AVEVA PI System data into Cumulocity changes that — enabling use cases that were previously out of reach:

Predictive process optimization — Feed live and historical tag data directly into ML models to anticipate process deviations before they impact production.
Richer operational insights — Surface time-series data in real-time dashboards and anomaly detection pipelines to give operators and engineers a clearer picture of what’s happening across their assets.
ML model training & inference — Use decades of high-fidelity sensor data to train models, then keep those models accurate with a continuous stream of live input signals.
Predictive maintenance & quality control — Drive maintenance scheduling and quality decisions from actual equipment behavior rather than fixed intervals or manual inspection.
OT/IT convergence — Break down the barrier between operational and enterprise systems, creating a unified data foundation for cross-functional teams.

This guide walks you through connecting an AVEVA PI System (Historian) to Cumulocity using a Python-based microservice and thin-edge. The integration works by running a lightweight Python microservice alongside thin-edge.io — Cumulocity’s open-source edge agent — which handles secure northbound communication, local buffering, and device management out of the box. Together, they bridge your PI Server’s Web API endpoint with Cumulocity’s cloud platform, translating PI tag data into Cumulocity measurements in real time.

By the end of this guide, you’ll have real-time industrial data flowing from your AVEVA PI System into Cumulocity, enabling dashboards, alerts, analytics, and integration with downstream IT systems — without disrupting your existing OT infrastructure.

Use Cases

This solution is ideal for:

Industrial IoT data ingestion – Bridge legacy AVEVA PI Systems to modern IoT platforms
Edge gateway integration – Deploy at the edge for local processing
SCADA to IoT bridging – Connect operational technology (OT) to IT systems
Real-time plant monitoring – Stream live process data to the cloud
Predictive maintenance – Feed AVEVA PI System data into analytics pipelines

What You’ll Build

A complete data pipeline that:

Reads industrial data from AVEVA PI System via PI Web API
Publishes data to a local MQTT broker
Routes telemetry through thin-edge.io gateway
Delivers data to Cumulocity IoT platform

Key Benefits:

Live configuration updates without service restarts
Edge-friendly deployment via Cumulocity Software Management
Remote configuration management from the cloud
Automatic configuration reload on changes

Architecture Overview

Here’s how the components work together:

The thin-edge Connector for AVEVA PI is deployed to a docker environment and is acting as a bridge between the PI Web API and MQTT Broker of thin-edge.io. thin-edge.io itself can be installed locally on the machine or also run as a container. It bridges the communication from MQTT to Cumulocity.

With Cumulocity Device Management thin-edge.io and the connector is fully remote managed including installation/deinstallation, software updates and configuration management.

Prerequisites

Before you begin, ensure you have:

Infrastructure Requirements

A VM or edge device running on Linux
Docker installed and running
unzip package installed

thin-edge.io Requirements

thin-edge.io agent installed and running
Device connected to Cumulocity
Device registered as a thin-edge device
thin-edge Mosquitto MQTT broker running and accessible
thin-edge container plugin installed

AVEVA PI System Requirements

Access credentials for PI Web API
Network connectivity from edge device to AVEVA PI System
List of AVEVA PI tags/datapoints you want to monitor

Step-by-step Guide

Step 1: Prepare the Software Package

You have two options to obtain the software:

Option A: Download Pre-built Package

Visit the GitHub Releases page
Download the latest pi_connector_{version}.zip package
Skip to Option B

Option B: Build from Source

Clone the repository:

git clone https://github.com/Cumulocity-IoT/thin-edge-aveva-pi-connector
cd thin-edge-aveva-pi-connector

Create the deployable package:

zip -r pi-historian-connector.zip \
         app.py \
         docker-compose.yaml \
         Dockerfile \
         requirements.txt

This creates pi-historian-connector.zip excluding development files.

Step 2: Upload to Cumulocity Software Repository

Log in to Cumulocity (Embedded IoT Platform as part of SAP APM)
Navigate to Management → Software repository
Click Add Software
Fill in the details:

Name PI Historian Connector

Software Type container-group

Version e.g., 1.0.0

File Upload your .zip package
Click Add Software to save

Step 3: Configure thin-edge.io

Register Configuration Files

The service uses two configuration files that need to be registered with thin-edge.io for remote management.

Edit the thin-edge configuration plugin:

sudo nano /etc/tedge/tedge-configuration-plugin.toml

Add the following configuration entries:

[[files]]
path = "/etc/tedge/tedge.toml"
type = "tedge.toml"

[[files]]
group = "tedge"
mode = 444
path = "/etc/tedge/plugins/tedge-log-plugin.toml"
type = "tedge-log-plugin"
user = "tedge"

[[files]]
path = "/etc/tedge/c8y/datapoints.json"
type = "pi_datapoints"
user = "tedge"
group = "tedge"
mode = 0o644

[[files]]
path = "/etc/tedge/c8y/pi_config.json"
type = "pi_config"
user = "tedge"
group = "tedge"
mode = 0o644

Restart thin-edge services:
```
sudo systemctl restart tedge-agent
```

Step 4: Create Configuration Files

4.1 Create PI System Configuration

Create a file named pi_config.json with your PI System connection details:

{
    "RECORDING_AT_TIME": "?time=",
    "POLL_INTERVAL": 90,
    "PI_USER": "your_pi_username",
    "PI_PASSWORD": "your_base64_encoded_password",
    "PI_URL": "https://pi-webapi.your-domain.com/piwebapi"
}

Configuration Parameters:

Parameter	Description	Example
`RECORDING_AT_TIME`	PI API query parameter for time-based data	`"?time="`
`POLL_INTERVAL`	Data polling interval in seconds	`90`
`PI_USER`	PI Web API username	`"pi_readonly_user"`
`PI_PASSWORD`	PI Web API password (base64-encoded)	`"cGFzc3dvcmQxMjM="`
`PI_URL`	PI Web API endpoint URL	`"https://pi-server.local/piwebapi"`

Tip: To encode your password in base64:

echo -n "your_password" | base64

4.2 Create Datapoints Configuration

Create a file named datapoints.json listing the PI tags you want to collect:

[
  "78FIQ301.A",
  "78FIC102.A",
  "REACTOR_TEMP_01",
  "FLOW_METER_MAIN"
]

Each entry should be a valid PI tag name from your PI System.

Step 5: Upload Configurations to Cumulocity

Now upload both configuration files to your thin-edge device:

Navigate to your device in Cumulocity:
- Go to Device Management → All devices
- Select your thin-edge device
Upload PI System configuration:
- Click the Configuration tab
- Click Add configuration snapshot
- Select type: pi_config
- Upload your pi_config.json file
- Click Upload
Upload datapoints configuration:
- Click Add configuration snapshot again
- Select type: pi_datapoints
- Upload your datapoints.json file
- Click Upload

Step 6: Deploy the Service

Navigate to your thin-edge device:
- Go to Device Management → All devices
- Select your thin-edge device
Install the software:
- Click the Software tab
- Click Install software
- Search for “PI Historian Connector”
- Select the version you uploaded
- Click Install
Monitor deployment:
- Watch the Operations tab for deployment status
- Wait for status to show Successful
Verify the service is running:
```
sudo docker ps | grep pi-historian
```
You should see the container running.

Step 7: Verify Data Flow

Check Service Logs

sudo docker logs -f

Look for messages indicating:

Successful connection to PI Web API
Data retrieval from PI tags
MQTT message publishing

Monitor MQTT Messages

mosquitto_sub -t 'te/device/main/#' -v

You should see telemetry data being published.

Check Cumulocity Measurements

Navigate to your device in Cumulocity
Click the Measurements tab
Verify that PI tag data is appearing

Managing Your Deployment

Update Configuration

To modify polling intervals, add new tags, or change credentials:

Edit your local pi_config.json or datapoints.json
Go to Device Management → Your device → Configuration
Upload the updated file
The service automatically detects and applies changes without restart

Update the Service

To deploy a new version:

Upload the new version to Software repository
Go to Device Management → Your device → Software
Select the new version and click Update

Troubleshooting

Service not starting:

sudo docker logs

Check thin-edge connectivity:

sudo tedge connect c8y
sudo systemctl status tedge-agent

Verify MQTT broker:

sudo systemctl status mosquitto

Check configuration files:

cat /etc/tedge/c8y/pi_config.json
cat /etc/tedge/c8y/datapoints.json

Advanced Topics

Data Flow Example

PI Tag: REACTOR_TEMP_01 = 127.5°C
     │
     ▼
PI Historian Service
     │ (polls every 90s)
     ▼
MQTT Topic: te/device/main/m/reactor_temp
     │ {"temperature": 127.5}
     ▼
Cumulocity Measurement
     │
     ▼
Dashboard Visualization

Custom Tag Mapping

You can extend datapoints.json to include friendly names:

[
  {
    "tag": "78FIQ301.A",
    "name": "Flow Rate - Inlet 301",
    "unit": "m³/h"
  },
  {
    "tag": "78FIC102.A",
    "name": "Temperature - Reactor 102",
    "unit": "°C"
  }
]

Future Enhancements

Planned improvements include:

Batch data ingestion for high-frequency tags
Local buffering during network outages
Advanced tag transformations and calculations
Built-in metrics and observability
Kubernetes-native deployment options

Contributing

We welcome contributions! Visit the repository: GitHub – Cumulocity-IoT/thin-edge-aveva-pi-connector: This repository contains a thinege plugin that…

Ways to contribute:

Improve documentation – Help others understand better
Add features – Extend functionality
Fix bugs – Report or resolve issues
Enhance performance – Optimize code

Please open an issue or submit a pull request.
